Most of this document is adapted from Andy's, so we follow his
convention by "...[separating] the definition from comments on discussion items by using
round brackets to refer to notes kept separate from the main text
e.g. (1) refers to point 1 in the notes section.". We have integrated
all comments to date into this document without special annotation.
ABSTRACT
This document describes a proposal for a combined Crystallographic Binary File (CBF)
and Image-supporting Crystallographic Information File (ImgCIF) format;
a simple self-describing binary format for efficient transport and
archiving of experimental data for the crystallographic community, and well as
for the presentation of other image data, such as PICT, GIF and JPEG, within
publication CIFs. With minor differences, both the binary CBF format and
the ASCII ImgCIF have a similar, CIF-like structure. All the information
other than actual binary data is presented as ASCII strings in both formats.
The formats differ only in the handling of line termination and the
actual presentation of the binary data of an image. The CBF format, presents
binary information as a raw string of octets, while the ImgCIF format
presents the binary information as ASCII-encoded lines. The format of the binary file, and the new CIF data-items are defined. In this document we
concentrate on the representation of images per se. The
CBF/imgCIF dictionary
includes additional data items related to crystallographic
data acquisition. Those additional data items are not discussed here.
Note:
- All numbers are decimal unless otherwise stated.
- The terms octet and byte refer to a group of eight bits.
1.0 INTRODUCTION
The Crystallographic Binary File (CBF) format is a complementary format
to the Crystallographic Information File (CIF)
[1], supporting efficient
storage of large quantities of experimental data in a self-describing
binary format (1). The Image-supporting
Crystallographic Information File (ImgCIF) format is a proposed
extension to CIF to assist in ASCII debugging and archiving
of CBF files and to allow for convenient and standardized inclusion
of images, such as maps, diagrams and molecular drawing into
publication CIFs. It is our expectation that, for large images,
the raw binary CBF format
will be used both with in laboratories and for interchange among
collaborating groups. For smaller chunks of binary data, either format
should be be suitable, with the ASCII ImgCIF format being more
appropriate for interchange and archiving.
The initial aim is to support efficient storage of raw experimental data
from area-detectors (images) with no loss of information compared to
existing formats. The format should be both efficient in terms of
writing and reading speeds, and in terms of stored file sizes, and
should be simple enough to be easily coded, or ported to new computer
systems.
Flexibility and extensibility are required, and later the storage of
other forms of data may be added without affecting the present definitions.
The aims are achieved by a simple file format, consisting of
lines of ASCII information defining information about the binary
data as CIF tag-value pairs and tables, and either raw octets of
binary data in delimited sections, or ASCII-based presentations
of the same binary information in similarly delimited sections.
The present version of the format only tries to deal with simple Cartesian
data. This is essentially the "raw" data from detectors
that is typically stored in commercial formats or individual formats
internal to particular institutes, but could be other forms
of data. It is hoped that CBF can replace individual laboratory or
institute formats for "home" built detector systems, be used as a
inter-program data exchange format, and may be offered as an output
choice by a number of commercial detector manufacturers specialising in
X-ray and other detector systems.
This format does not imply any particular demands on processing software
nor on the manner in which such software should work. Definitions of units,
coordinate systems, etc. may quite different. The clear precise
definitions within CIF, and hence CBF, help, when necessary, to
convert from one system to another. Whilst no strict demands are made,
it is clearly to be hoped that software will make as much use as is
reasonable of information relevant to the processing which is stored
within the file. It is expected that processing software will give
clear and informative error messages when they encounter problems within
CBF's or do not support necessary mechanisms for inputting a file.
1.1 CBF and "imgCIF"
CBF and "imgCIF" are two aspects of the same format. Since CIF's
are pure ASCII text files, a separate binary format is needed to be
defined to allow the combination of pseudo-ASCII sections and
binary data sections. The binary file format is the Crystallographic
Binary File (CBF). The ASCII sections are very close to the CIF
standard, but must use operating system independent "line separators".
In describing the ASCII sections, we use the notation
"\r\n" (for the pair of characters carriage return, line-feed)
for a line terminator would allow the ASCII sections to viewed with standard system
utilities on a very wide range of operating systems. However,
an API to read
the binary format must accept any of the following three alternative
line terminators as the end of an ascii line: "\r",
"\n" or "\r\n". An API to write CBF should
write "\r\n" as the line terminator, if at all possible.
imgCIF is also the name of the CIF dictionary which contains the terms
specific to describing the binary data (the orginal, designed by John Westbrook, without the
modifications in this proposal is avaliable from
http://ndbserver.rutgers.edu/NDB/mmcif. Thus a CBF
or ImgCIF files uses data names
from the imgCIF dictionary and other CIF dictionaries.
2.0 A SIMPLE EXAMPLE
Before fully describing the format we start by showing a simple, but
important and complete usage of the format; that of storing a single
detector image in a file together with a small amount of useful
auxiliary information. It is intened to be a useful example for people
who like working from examples, as opposed to full definitions. It
should also serve as an introduction or overview of the format defintion.
This example uses CIF DDL2 based dictionary items.
The example is an image of 768 by 512 pixels stored as 16 bit unsigned
integers, in little endian byte order. (This is the native byte ordering
on a PC.) The pixel sizes are 100.5 by 99.5 microns. Comment lines starting
with a hash sign (#) are used to explain the contents of the header.
Only the ASCII part of the file is shown, but comments are used to
describe the start of the binary section.
First the file is shown with the minimum of comments that a typical
outputting program might add. Then it is repeated, but with "over-
commenting" to explain the format.
Here is how a file might appear if listed on a PC or on a Unix system
using "more":
###CBF: VERSION 0.6
# Data block for image 1
data_image_1
_entry.id 'image_1'
# Sample details
_chemical.entry_id 'image_1'
_chemical.name_common 'Protein X'
# Experimental details
_exptl_crystal.id 'CX-1A'
_exptl_crystal.colour 'pale yellow'
_diffrn.id DS1
_diffrn.crystal_id 'CX-1A'
_diffrn_measurement.diffrn_id DS1
_diffrn_measurement.method Oscillation
_diffrn_measurement.sample_detector_distance 0.15
_diffrn_radiation_wavelength.id L1
_diffrn_radiation_wavelength.wavelength 0.7653
_diffrn_radiation_wavelength.wt 1.0
_diffrn_radiation.diffrn_id DS1
_diffrn_radiation.wavelength_id L1
_diffrn_source.diffrn_id DS1
_diffrn_source.source synchrotron
_diffrn_source.type 'ESRF BM-14'
_diffrn_detector.diffrn_id DS1
_diffrn_detector.id ESRFCCD1
_diffrn_detector.detector CCD
_diffrn_detector.type 'ESRF Be XRII/CCD'
_diffrn_detector_element.id 1
_diffrn_detector_element.detector_id ESRFCCD1
_diffrn_frame_data.id F1
_diffrn_frame_data.detector_element_id 1
_diffrn_frame_data.array_id 'image_1'
_diffrn_frame_data.binary_id 1
# Define image storage mechanism
#
loop_
_array_structure.id
_array_structure.encoding_type
_array_structure.compression_type
_array_structure.byte_order
image_1 "unsigned 16-bit integer" none little_endian
loop_
_array_intensities.array_id
_array_intensities.binary_id
_array_intensities.linearity
_array_intensities.undefined_value
_array_intensities.overload_value
image_1 1 linear 0 65535
# Define dimensionality and element rastering
loop_
_array_structure_list.array_id
_array_structure_list.index
_array_structure_list.dimension
_array_structure_list.precedence
_array_structure_list.direction
image_1 1 768 1 increasing
image_1 2 512 2 decreasing
loop_
_array_element_size.array_id
_array_element_size.index
_array_element_size.size
image_1 1 100.5e-6
image_1 2 99.5e-6
loop_
_array_data.array_id
_array_data.binary_id
_array_data.data
image_1 1
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-Size: 374578
X-Binary-ID: 1
X-Binary-Element-Type: "unsigned 16-bit integer"
Content-MD5: jGmkxiOetd9T/Np4NufAmA==
START_OF_BIN
*************'9*****`********* ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
Here the file is shown again, but this time with many comment
lines added to explain the format:
###CBF: VERSION 0.6
# This line starting with a "#" is a CIF and CBF comment line,
# but the first line with the three "#"s is a CBF identifier.
# (a "magic number") The text "###_CBF: VERSION" identifies
# the file as a CBF and must be present as the very first line of
# every CBF file. Following "VERSION" is the version number of
# the file, which is the corresponding version of the CBF/imgCIF
# extensions dictionary and supporting documentation. A version
# 0.6 CIF should be readable by any program which fully supports
# the version 1.0 CBF definitions.
# Comment lines and white space (blanks and new lines) may appear
# anywhere outside the binary sections.
# In a CIF, the descriptive tags and values may be presented in
# any convenient order, e.g. the data could come first, and the
# parameters necessary to interpret the data could come later.
# This order-independent convention holds for an imgCIF file, but
# for a CBF, all the tags and values describing binary data (i.e.
# all the tags other than those in the ARRAY_DATA category) should
# be presented before the binary data, in the form of a header.
# This does not mean that there cannot be more useful information
# after the binary data. There could be another full header and
# more blocks of binary data. All we are saying is that, in
# the interest of efficiency in processing a CBF, the parameters
# that relate to a particular block of binary data must appear
# earlier in the CBF than the block itself.
# The header begins with "data_", which is the CIF token to
# identify a data block. Within a data block, any given tag may
# be presented only once, either directly with an immediately
# following value, or as one of the column headings for the rows
# of a table. If you will need to resuse the same tag, you will
# have to start a new data block.
# Data block for image 1
data_image_1
# We've chosen to call this data block 'image_1', but this was an
# arbitary choice. Within a data block a data item may only be used
# once.
_entry.id 'image_1'
# Sample details
_chemical.entry_id 'image_1'
_chemical.name_common 'Protein X'
# The apostrophes enclose the string which contains a space.
# A double quote (") could have been used, just as well.
# There is also a third way to quote string, with the string
# "\n;", i.e. with a semicolon at the beginning of a line
# which allows multi-lined strings to be presented. We'll
# use that form of text quotation for the binary data.
# Experimental details
_exptl_crystal.id 'CX-1A'
_exptl_crystal.colour 'pale yellow'
_diffrn.id DS1
_diffrn.crystal_id 'CX-1A'
_diffrn_measurement.diffrn_id DS1
_diffrn_measurement.method Oscillation
_diffrn_measurement.sample_detector_distance 0.15
_diffrn_radiation_wavelength.id L1
_diffrn_radiation_wavelength.wavelength 0.7653
_diffrn_radiation_wavelength.wt 1.0
_diffrn_radiation.diffrn_id DS1
_diffrn_radiation.wavelength_id L1
_diffrn_source.diffrn_id DS1
_diffrn_source.source synchrotron
_diffrn_source.type 'ESRF BM-14'
_diffrn_detector.diffrn_id DS1
_diffrn_detector.id ESRFCCD1
_diffrn_detector.detector CCD
_diffrn_detector.type 'ESRF Be XRII/CCD'
_diffrn_detector_element.id 1
_diffrn_detector_element.detector_id ESRFCCD1
_diffrn_frame_data.id F1
_diffrn_frame_data.detector_element_id 1
_diffrn_frame_data.array_id 'image_1'
_diffrn_frame_data.binary_id 1
# Many more data items can be defined, but the above gives the idea
# of a useful minimum set (but not minimum in the sense of
# compulsory, the above data items are optional in a CIF or CBF).
# Define image storage mechanism
#
# Notice that we did not include a binary ID here. The idea of
# the ARRAY_STRUCTURE category is to present parameters which
# could be common to multiple blocks of binary data, which would
# all have the same array ID, but would have distinct binary ID's
loop_
_array_structure.id
_array_structure.encoding_type
_array_structure.compression_type
_array_structure.byte_order
image_1 "unsigned 16-bit integer" none little_endian
# On the other hand, we do provide a binary ID for ARRAY_INTENSITIES,
# since there might be different paremeters for each binary block.
# We could have left it out here, since there is only one block and
# the default binary ID happens to be 1
loop_
_array_intensities.array_id
_array_intensities.binary_id
_array_intensities.linearity
_array_intensities.undefined_value
_array_intensities.overload_value
image_1 1 linear 0 65535
# Define dimensionality and element rastering
# Here the size of the image and the ordering (rastering) of the data
# elements is defined. The CIF "loop_" structure is used to
# define different dimensions. (It can be used for defining multiple
# images.)
loop_
_array_structure_list.array_id
_array_structure_list.index
_array_structure_list.dimension
_array_structure_list.precedence
_array_structure_list.direction
image_1 1 768 1 increasing
image_1 2 512 2 decreasing
loop_
_array_element_size.array_id
_array_element_size.index
_array_element_size.size
image_1 1 100.5e-6
image_1 2 99.5e-6
# The "array_id" identifies data items belong to the same array.
# Here we have chosen the name "image_1", but another name could
# have been used, so long as it's used consistently. The "index"
# component refers to the dimension being defined, and the
# "dimension" component defines the number of elements in that
# dimension. The "precedence" component defines which precedence
# of rastering of the data. In this case the first dimension is the faster
# changing dimension. The "direction" component tells us the
# direction in which the data rasters within a dimension. Here the
# data rasters faster from minimum elements towards the maximum
# element ("increasing") in the first dimension, and more
# slowly from the maximum element towards the minimum element in
# the second dimension. (This is the default rastering order.)
# The storage of the binary data is now fully defined.
# Further data items could be defined, but we are ready to
# present the data. That is done with the ARRAY_DATA category.
# The start of this category marks the end of the header
# (Well, almost the end, there is a bit more header information
# below).
loop_
_array_data.array_id
_array_data.binary_id
_array_data.data
image_1 1
# The binary data itself will come just a little further down,
# as the essential part of the value of _array_data.data, which
# begins as semicolon-quoted text. The line immediately after
# the line with the semicolon is a MIME boundary marker. As for
# all MIME boundary markers, it begins with "--". The next
# few lines are MIME headers, describing some useful information
# we will need to process the binary section. MIME headers can
# appear in different orders, and can be very confusing (look
# at the raw contents of a email message with attachments), but
# there is only a few headers which is have to be understood to
# process a CBF:
#
# The "Content-Type" header may be any of discrete types
# permitted in RFC 2045; "application/octet-stream" is
# recommended. If an octet stream was compressed, the
# compression should be specified by the parameter
# 'conversions="x-CBF_PACKED"' or by specifying
# one of the other compression types.
#
# The "Content-Transfer-Encoding" header should be 'BINARY'
# for a CBF. We'll consider the other values used for imgCIF
# below.
#
# The "X-Binary-Size" header specifies the size of the
# binary data in octets. If compression was used, this size
# is the size after compression, including any book-keeping
# fields, but not the 8 bytes for the compression type.
#
# The "X-Binary-Element-Type" header specifies the
# type of binary data in the octets, using the same
# descriptive phrases as in _array_structure.encoding_type.
# The default value is "unsigned 32-bit integer".
#
# The MIME header items are followed by an empty line and then by
# a special sequence marked here as 'START_OF_BIN', consisting of
# Control-L, Control-Z, Control-D to stop printing on most systems,
# and then a single binary flag character of hexadecimal value D5
# (213 decimal). The binary data follows immediately after this
# flag character.
#
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-Size: 374578
X-Binary-ID: 1
X-Binary-Element-Type: "unsigned 16-bit integer"
Content-MD5: jGmkxkrpnizOetd9T/Np4NufAmA==
START_OF_BIN
*************'9*****`********* ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
# After the last octet (i.e. byte) of the binary data, there is a
# special trailer "\n--CIF-BINARY-FORMAT-SECTION----\n;"
# which repeats the initial bounday marker with an extra "--"
# at the end (a MIME convention for the last boundary marker), and
# then the closing semicolon quote for a text section. This
# is essential in an imgCIF, and we include it in a CBF for
# consistency.
OVERVIEW OF THE FORMAT
This section describes the major "components" of the CBF format.
- CBF is a binary file, containing self-describing array data e.g. one
or more images, and auxiliary data e.g. describing the experiment.
- Except for the handling of line terminators, the way binary data
is presented, and more liberal rules in ordinger information, an
ASCII imgCIF file is the same as a CBF binary file.
- A CBF consists of pseudo-ASCII text header sections, which are "lines" of
no more than 80 ASCII characters separated by "line separators" which are the pair of
ASCII characters carriage return and line-feed (ASCII 13, ASCII 10),
followed by zero, one, or more binary sections presented as "binary
strings". This structure may be repeated.
- An imgCIF consists of ASCII lines of no more than 80 characters using the
the normal line termination conventions of the current system (e.g.
ASCII 10 in UNIX) with MIME-encoded binary strings at any
appropriate point in the file.
- The very start of the file has an identification item (magic number)
(2). This item
also describes the CBF version or level. The identifier is:
###CBF: VERSION
which must always be present so that a program can easily identify
whether or not a file is a CBF, by simply inputting the first 15
characters. (The space is a blank (ASCII 32) and not a tab. All
identifier characters are uppercase only.)
The first hash means that this line within a CIF would be a comment
line, but the three hashes mean that this is a line describing the
binary file layout for CBF. (All CBF internal identifiers start with
the three hashes, and all other must immediately follow a "line
separator".) No whitespace may precede the first hash sign.
Following the file identifier is the version number of the file. e.g.
the full line might appear as:
###CBF: VERSION 0.6
The version number must be separated from the file identifier
characters by whitespace e.g. a blank (ASCII 32).
The version number is defined as a major version number and minor
version number separated by the decimal point. A change in the major
version may well mean that a program for the previous version cannot
input the new version as some major change has occurred to CBF
(3). A
change in the minor version may also mean incompatibility, if the CBF
has been written using some new feature. e.g. a new form of linearity
scaling may be specified and this would be considered a minor version
change. A file containing the new feature would not be readable by a
program supporting only an older version of the format.
Note:
Until we reach major version 1 (the first official release), the
rules are a little more relaxed. While there will be some effort at
upwards compatability, in order to ensure a reasonable agreed specification
without too many strange artifacts, changes between minor versions
may, unfortunately, introduce incompatabilities which require
program changes to still read CBFs compliant with an earlier draft,
e.g. the change in the "magic number" and from binary sections to
binary strings in going to version 0.3, and a removal of the
redundant parts of the binary header in going to version 0.6.
Naturally, such changes should be sufficiently well documented to allow
for conversions.>>>
- Header Information:
- The start of an header section is delimited by the
usual CIF "data_" token. Optionally, the formerly specified
header identifier,
###_START_OF_HEADER
may be used before the "data_" taken, followed by the carriage return, line-feed pair,
as an aid in debugging, but it is no longer required. (Naturally, another carriage return,
line-feed pair should immediately precedes this and all other CBF identifiers, with
the exception of the CBF file identifier which is at the very start of the
file.)
- A header section, including the identification items which delimit
it, uses only ASCII characters, and is divided into "lines". The "line
separator" symbols, "\r\n" (carriage return, line-feed) are the same regardless
of the operating system on which the file is written. (This is an
importance difference with CIF, but must be so, as the file contains
binary data, so cannot be translated from one O.S. to another, which is
the case for ASCII text files.) While a properly functioning CBF API
should write the full "\r\n" line separator, it should recognize
any of three sequences "\r", "\n", "\r\n" as valid
line separators, so that hand-edited headers will not be rejected.
- The header section within the delimiting identification items
obeys all CIF rules [1] with the
exception of the line separators.
e.g.
- "Lines" are a maximum of 80 characters long. (For CBF it is probably
best to allow for this maximum to be larger.)
- The tokens "data_" and "loop_" have special meaning to CIF, and
should not be used except in their indicated places. The tokens
"save_", "stop_" and "global_" also have special meaning to CIF's
parent language, STAR, and also should not be used.
- All data names (tags) start with an underscore character.
- The hash symbol (#) (outside a character string) means that all text
up to the line separator is a comment.
- Whitespace outside of character strings is not significant.
- Data names are case insensitive.
- The data item follows the data name separator, and may be of one of
two types: character string (char) or number (numb). (The type is
specified for each data name.)
- Character strings may be delimited with single of double quotes, or blocks of
text may be delimited by semi-colons occurring as the first character on
a line.
- The "loop_" mechanism allows a data name to have multiple values.
Immediately following the "loop_", one or more data names are listed without
their values, as column headings. Then one or more rows of values
are given.
Any CIF data name may occur within the header section.
- A single header section may contain one or more data blocks (CIF
terminology).
- The end of the header information is marked by
coming to the tags from the "ARRAY_DATA" category. The formerly
specifier special
identifier:
###_END_OF_HEADER
followed by carriage return, line-feed, may be used as well as an aid to
debugging, but it is not required.
- The header information must contain sufficient data names to fully
describe the binary data section(s) which follow(s).
- Binary Information:
Note: Under CBFlib "binary sections" have been replaced by "binary strings"
values within a data name/value pair. The structure of the proposed
"binary string" is similar to the former binary sections, but there are
significant differences.
- Before getting to the binary data, itself, there are some preliminaries
to allow a smooth transition from the conventions of CIF to those of
raw streams of "octets" (8-bit bytes). The binary data is
given as the essential part of a specially formatted semicolon-delimited
CIF multi-line text string. This text string is the value associated with the
tag "_array_data.data".
- Within that text string, the conventions developed for
transmitting email messages including binary attachments are followed.
There is secondary ASCII header information, formatted as Multipurpose
Internet Mail Extensions (MIME) headers (see RFCs 2045-49 by
Freed, et. al). The bounday marker for the beginning of all this
is the special string
--CIF-BINARY-FORMAT-SECTION--
at the beginning of a line. The initial "--" says that
this is a MIME boundary. We cannot put "###" in front
of it and conform to MIME conventions. Immediately after the boundary
marker are MIME headers, describing some useful information
we will need to process the binary section. MIME headers can
appear in different orders, and can be very confusing (look
at the raw contents of a email message with attachments), but there
is only a few headers with a narrow range of values which is have
to be understood to process a CBF (as opposed of an imgCIF, for which the
headers can be more varied):
- The "Content-Type" header may be any of discrete types
permitted in RFC 2045; "application/octet-stream" is
recommended. If an octet stream was compressed, the
compression should be specified by the parameter
'conversions="x-CBF_PACKED"' or by specifying
one of the other compression types.
- The "Content-Transfer-Encoding" header should be 'BINARY'
for a CBF. We'll consider the other values used for imgCIF
below.
- The "X-Binary-Size" header specifies the size of the
binary data in octets. If compression was used, this size
is the size after compression, including any book-keeping
fields, but not the 8 bytes for the compression type.
- The "X-Binary-Element-Type" header specifies the
type of binary data in the octets, using the same
descriptive phrases as in _array_structure.encoding_type.
The default value is "unsigned 32-bit integer".
The MIME header items are followed by an empty line and then by
a special sequence marked here as 'START_OF_BIN', consisting of
Control-L, Control-Z, Control-D to stop printing on most systems,
and then a single binary flag character of hexadecimal value D5
(213 decimal). The binary data follows immediately after this
flag character.
In general, if the value given for "Content-Transfer-Encoding" is one of the
real encodings: "BASE64", "QUOTED-PRINTABLE", "X-BASE8",
"X-BASE10" or "X-BASE16", this file is an imgCIF.
For either a CBF or an imgCIF the optional "Content-MD5" header provides a much more
sophisticated check on the integrity of the binary data.
In a CBF, the raw binary data begins after an empty line terminating
the MIME headers and after the START_OF_BIN identifier.
"START_OF_BIN" contains bytes to separate the "ASCII" lines
from the binary data, bytes to try to stop the listing of the header,
bytes which define the binary identifier which should match the
"binary_id" defined in the header, and bytes which define the
length of the binary section.
| Octet | Hex | Decimal | Purpose
|
|---|
| 1 | 0C | 12 | (ctrl-L) End the current page
|
| 2 | 1A | 26 | (ctrl-Z) Stop listings in MS-DOS
|
| 3 | 04 | 04 | (Ctrl-D) Stop listings in UNIX
|
| 4 | D5 | 213 | Binary section begins
|
| 5..5+n-1 | | | Binary data (n octets)
|
Only bytes 5..5+n-1 are encoded for an imgCIF file
using the indicated Content-Transfer-Encoding.
Note: Earlier versions of the specification included three 8-byte words
of information in binary which replicated information now available in
the MIME header:
| 5..12 | | | Binary Section Identifier
(See _array_data.binary_id)
64-bit, little endian
|
| 13..20 | | | the size (n) of the
binary section in octets
(i.e. the offset from octet
29 to the first byte following
the data)
|
| 21..28 | | | Compression type:
| CBF_NONE | 0x0040 (64)
| | CBF_CANONICAL | 0x0050 (80)
| | CBF_PACKED | 0x0060 (96)
| | ... |
|
|
followed by binary data. These three 8-byte words are no longer included when
a MIME header is provided. In addition, in still earlier versions, the size
given in the second 8-byte word was n+8, rather than n.
The binary characters serve specific purposes:
- The Control-L will terminate the current page in listings
on most operating systems.
- The Control-Z will stop the listing of the file on MS-DOS
type operating systems.
- The Control-D will stop the listing of the file on Unix
type operating systems.
- The unsigned byte value 213 (decimal) is binary 11010101.
(Octal 325, and hexadecimal D5).
This has the eighth bit set so can be used for error checking
on 7-bit transmission. It is also asymmetric, but with the first
bit also set in the case that the bit order could be reversed
(which is not a known concern).
- (The carriage return, line-feed pair before the START_OF_BIN
and other lines can also be used to check that the file has not
been corrupted e.g. by being sent by ftp in ASCII mode.)
- The "line separator" immediately precedes the "start of binary
identifier", but blank spaces may be added prior to the preceding
"line separator" if desired (e.g. to force word or block alignment).
- The binary data does not have to completely fill the bytes defined
by the byte length value, but clearly cannot be greater than this
value (except when the value zero has been stored, which means that
the size is unknown, and no other headers follow). The values of
any unused bytes are undefined.
- At exactly the byte following the full binary section as defined by
the length value is the end of binary section identifier. This consists
of the carriage return / line feed pair followed by:
--CIF-BINARY-FORMAT-SECTION--
;
with each of these lines followed by the carriage return / line feed pair.
This brings us back into a normal CIF environment
The first "line separator" separates the binary data from the
pseudo-ASCII line.
This identifier is in a sense redundant since the binary data
length value tells the a program how many bytes to jump over to
the end of the binary data. However, this redundancy has been
deliberately added for error checking, and for possible file
recovery in the case of a corrupted file.
This identifier must be present at the end of every block of
binary data.
- Whitespace may be used within the pseudo-ASCII sections prior to the
"start of binary section" identifier to align the start binary data
sections to word or block boundaries. Similar use may be made of unused
bytes in binary sections. However, no blank lines should be introduced
among the MIME headers, since that would terminate processing of those
headers and start the scan for binary data.
However, in general no guarantee is made of block nor word alignment
in a CBF of unknown origin.
- The end of the file need not be not explicitly indicated, but
including a comment of the form:
###_END_OF_CBF
(including the carriage return, line-feed pair) can help in debugging.
- All binary data described in a single data block should follow the
header section prior to another data block, or the end of the
file, so allow for the most efficient processing of CBF files.
However, since binary strings can be parsed anywhere within the
context of a CBF or imgCIf file, it is recommended that processing
software from CBF accept such strings in any order and it is mandatory
that processing software for imgCIF accept such string in any order.
The binary identifier values used within a given data block section, and
hence the binary data must be unique for any
given array_id, and, it would be best to make them truly unique.
A different data block may reuse binary identifier values.
(This allows concatenation of files without re-numbering the
binary identifiers, and provides a certain level of localization
of data within the file, to avoid programs having to search
potentially huge files for missing binary sections.)
- The recommended file extension for a CBF is: cbf
This allows users to recognise file types easily, and gives programs a
chance to "know" the file type without having to prompt the user.
Although they should check for at least the file identifier to
ensure that the file type is indeed a CBF.
- The recommended file extensions for imgCIF are: icf or cif
(use of "cif" subject to IUCr approval).
- CBF format files are binary files and when ftp is used to transfer
files between different computer systems "binary" or "image" mode
transfer should be selected.
- imgCIF files are ASCII files and when ftp is used to transfer
files between different computer systems "ascii"
transfer should be selected.
3.1 SIMPLE EXAMPLE OF THE ORDERING OF IDENTIFIERS
Here only the ASCII part of the file structuring identifiers is shown.
The CIF data items are not shown, apart from the "data_" identifier
which indicates the beginning of a data block.
This shows the structuring of a simple example e.g. one header section
followed by one binary section. Such as could be used to store a
single image.
###CBF: VERSION 0.3
data_
### ... various CIF tags and values here
loop_
array_data.id
array_data.binary_id
array_data.data
image_1 1
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-ID: 1
Content-MD5: jGmkxiOetd9T/Np4NufAmA==
START_OF_BIN
*************'9*****`********* ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
###_END_OF_CBF
3.2 MORE COMPLICATED EXAMPLE OF THE ORDERING OF IDENTIFIERS
Here only the ASCII part of the file structuring identifiers is shown.
The CIF data items are not shown, apart from the "data_" identifier
which indicates the beginning of a data block.
This shows the a possible structuring of a more complicated example.
Two header sections, the first contains two data blocks and defines
three binary sections. CIF comment lines, starting with a hash (#) are
used to example the structure.
###CBF: VERSION 0.6
# CBF file written by cbflib v0.6
# A comment cannot appear before the file identifier, but can appear
# anywhere else, except within the binary sections.
# Here the first data block starts
data_
### ... various CIF tags and values here
### but none that define array data items
# The "data_" identifier finishes the first data block and starts the
# second
data_
### ... various CIF tags and values here
### including ones that define array data items
loop_
array_data.array_id
array_data.binary_id
array_data.data
image_1 1
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-Size: 3745758
X-Binary-ID: 1
X-Binary-Element-Type: "signed 32-bit integer"
Content-MD5: 1zsJjWPfol2GYl2V+QSXrw==
START_OF_BIN
<D5>^P<B8>P^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@ ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
# Following the "end of binary" identifier the file is pseudo-ASCII
# again, so comments are valid up to the next "start of binary"
# identifier. Note that we have bumped the binary ID.
image_1 2
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-Size: 3745758
X-Binary-ID: 2
X-Binary-Element-Type: "signed 32-bit integer"
Content-MD5: xR5kxiOetd9T/Nr5vMfAmA==
START_OF_BIN
<D5>^P<B8>P^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@^@ ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
# Third binary section, note that we have a new array id.
image_2 3
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-ID: 3
Content-MD5: yS5kxiOetd9T/NrqTLfAmA==
START_OF_BIN
*************'9*****`********* ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
# Second Header section
data_
### ... various CIF tags and values here
### including ones that define array data items
# Since we only have one block left, we won't use a loop
array_data.id image
array_data.binary_id 1
array_data.data
# Note that I can put a comment here
;
--CIF-BINARY-FORMAT-SECTION--
Content-Type: application/octet-stream;
conversions="x-CBF_PACKED"
Content-Transfer-Encoding: BINARY
X-Binary-ID: 1
Content-MD5: fooxiOetd9T/serNufAmA==
START_OF_BIN
*************'9*****`********* ...
[This is where the raw binary data would be -- we can't print it here]
--CIF-BINARY-FORMAT-SECTION----
;
###_END_OF_CBF
DATA NAME CATEGORIES
John Westbrook has proposed a number of data name categories as part of
his DDL2 based "imgCIF" dictionary. This category list may be expanded
to cover a structuring of the often multiple data-sets which might be used
in a structurial investigation. Here we only consider the categories
concerned with storing an image (or other N-dimensional topographically
regular cartesian grid).
The _array_* categories cover all data names concerned with
the storage of images or regular array data.
Data names from any of the existing categories may be relevant as
auxiliary information in the header section, but data names from the
_diffrn_ category, are likely to be the most relevant, and a
number of new data names in this category are necessary.
The "array" Class of Binary Data
The "array" class is used to store regular arrays of data values, such
as 1-D histograms, area-detector data, series of area-detector data, and
volume data. Normally such data is regularly spaced in space or time,
however spatial distorted data could nevertheless be stored in such a format.
There is only one data "value" stored per lattice position, although that
value may be of type complex.
The "array" class is defined by data names from the ARRAY_STRUCTURE
and ARRAY_STRUCTURE_LIST categories.
Here is a short summary of the data names and their purposes.
"Array" Dimensions and Element Rastering and Orientation
The array dimension sizes, i.e. the number of elements in each dimension
are defined by _array_structure_list.dimension.
Which takes an integer value. This is used in a loop together with
the _array_structure_list.index
item to define the different dimensions for one or more arrays.
Fundamental to treating a long line of data values as a 2-D image or
an N-dimensional volume or hyper-volume is the knowledge of the manner
in which the values need to be wrapped. For the raster orientation to
be meaningful we define the sense of the view:
For a detector image the sense of the view is defined as that looking
from the crystal towards the detector.
(For the present we consider only an equatorial plane geometry, with
2-theta = 0; the detector as being vertically mounted.)
The rastering is defined by the three data names
_array_structure_list.index, _array_structure_list.precedence, and
_array_structure_list.direction data names.
index refers to the dimension index i.e. In an image 1 refers to the
X-direction (horizontal), 2 refers to the Y-direction (vertical).
precedence refers to the order in which the data in wrapped.
direction refers the direction of the rastering for that index.
We define a preferred rastering orientation,
which is the default if the keyword is not defined. This is with the
start in the upper-left-hand corner and the fastest changing direction
for the rastering horizontally, and the slower change from top to bottom.
(Note: With off-line scanners the rastering type depending on which way
round the imaging plate or film is entered into the scanner. Care may
need to be taken to make this consistent.)
"Array_Structure" Examples
To define an image array of 1300 times 1200 elements, with the raster
faster in the first dimension, from left to right, and slower in the
second dimension from top to bottom, the following header section
might be used:
# Define image size and rastering
loop_
_array_structure_list.array_id
_array_structure_list.index
_array_structure_list.dimension
_array_structure_list.precedence
_array_structure_list.direction
image_1 1 1300 1 increasing
image_1 2 1200 2 decreasing
To define two arrays, the first a volume of 100 times 100 times 50
elements, fastest changing in the first dimension, from left to right,
changing from bottom to top in the second dimension, and slowest
changing in the third dimension from front to back; the second an image
of 1024 times 1280 pixels, with the second dimension changing fastest
from top to bottom, and the first dimension changing slower from left
to right; the following header section might be used:
# Define array sizes and rasterings
loop_
_array_structure_list.array_id
_array_structure_list.index
_array_structure_list.dimension
_array_structure.precedence
_array_structure.direction
volume_a 1 100 1 increasing
volume_a 2 100 2 increasing
volume_a 3 50 3 increasing
slice_1 1 1024 2 increasing
slice_1 2 1280 1 decreasing
"Array" Element Intensity Scaling
Existing data storage formats use a wide variety of methods for storing
physical intensities as element values. The simplest is a linear
relationship, but square root and logarithm scaling methods have
attractions and are used. Additionally some formats use a lower dynamic
range to store the vast majority of element values, and use some other
mechanism to store the elements which over-flow this limited dynamic
range. The problem of limited dynamic range storage is solved by the data
compression methods byte_offsets and predictor_huffman
(see next Section), but the possibility of defining non-linear scaling
must also be provided.
The _array_intensities.linearity data item specifies how the
intensity scaling is defined. Apart from linear scaling, which is
specified by the value linear, two other methods are available
to specify the scaling.
One is to refer to the detector system, and then knowledge of the
manufacturers method will either be known or not by a program. This has
the advantage that any system can be easily accommodated, but requires
external knowledge of the scaling system.
The recommended alternative is to define a number of standard intensity
linearity scaling methods, with additional data items when needed. A
number of standard methods are defined by _array_intensities.linearity
values: offset, scaling_offset, sqrt_scaled, and
logarithmic_scaled.
The "offset" methods require the data item _array_intensities.offset
to be defined, and the "scaling" methods require the data item
_array_intensities.scaling to be defined.
The above scaling methods allow the element values to be converted to a
linear scale, but do not necessarily relate the linear intensities to
physical units. When appropriate the data item _array_intensities.gain
can be defined. Dividing the linearized intensities by the value of
_array_intensities.gain should produce counts.
Two special optional data flag values may be defined which both refer to
the values of the "raw" stored intensities in the file (after
decompression if necessary), and not to the linearized scaled values.
_array_intensities.undefined_value specifies a value which
indicates that
the element value is not known. This may be due to data missing e.g. a
circular image stored in a square array, or where the data values are
flagged as missing e.g. behind a beam-stop.
_array_intensities.overload_value indicates the intensity value
at which and above, values are considered unreliable. This is usually due to
saturation.
"Array_intensities" Example
To define the characteristics of image_1 as linear with a gain
of 1.2, and an undefined value of 0, and a saturated (overloaded)
value of 65535, the following header section might be used:
# Define image intensity scaling
loop_
_array_intensities.array_id
_array_intensities.binary_id
_array_intensities.linearity
_array_intensities.gain
_array_intensities.undefined_value
_array_intensities.overload_value
image_1 1 linear 1.2 0 65535
DATA COMPRESSION
One of the primary aims of imgCIF / CBF is to allow efficient storage, and
efficient reading and writing of data, so data compression is of great
interest. Despite the extra CPU over-heads it can very often be faster
to compress data prior to storage, as much smaller amounts of data need
to be written to disk, and disk I/O is relatively slow. However, optimum
data compression can result in complicated algorithms, and be highly
data specific.
In CBFlib version 0.1, Paul Ellis has coded two lossless compression
algorithms: canonical and packed.
Canonical-code compression
The canonical-code compression scheme encodes errors in two ways: directly or indirectly.
Errors are coded directly using a symbol corresponding to the error value. Errors
are coded indirectly using a symbol for the number of bits in the (signed) error,
followed by the error iteslf.
At the start of the compression, CBFLIB constructs a table containing a set of symbols,
one for each of the 2^n
direct codes from -(2^(n-1)) .. 2^(n-1)
-1, one for a stop code, and one for each of the maxbits
-n
indirect codes, where n
is chosen at compress time and maxbits
is the maximum number of bits in an error. CBFLIB then assigns to each symbol a
bit-code, using a shorter bit code for the more common symbols and a longer bit code
for the less common symbols. The bit-code lengths are calculated using a Huffman-type
algorithm, and the actual bit-codes are constructed using the canonical-code algorithm
described by Moffat, et al. (International Journal of High
Speed Electronics and Systems, Vol 8, No 1 (1997) 179-231).
The structure of the compressed data is:
| Byte | Value
|
|---|
| 1 .. 8 | Number of elements (64-bit little-endian number)
|
| 9 .. 16 | Minimum element
|
| 17 .. 24 | Maximum element
|
| 25 .. 32 | Repeat length (currently unused)
|
| 33 | Number of bits directly coded, n
|
| 34 | Maximum number of bits encoded, maxbits
|
| 35 .. 35+2^n-1 | Number of bits in each direct code
|
| 35+2^n | Number of bits in the stop code
|
| 35+2^n+1 .. 35+2^n+maxbits-n
| Number of bits in each indirect code
|
| 35+2^n+maxbits-n+1 ..
| Coded data
|
CCP4-style compression
The CCP4-style compression writes the errors in blocks . Each block begins with a
6-bit code. The number of errors in the block is 2^n,
where n
is the value in bits 0 .. 2.
Bits 3 .. 5 encode the number of bits in each error:
Value in bits 3 .. 5 |
Number of bits in each error |
| 0 | 0 |
| 1 | 4 |
| 2 | 5 |
| 3 | 6 |
| 4 | 7 |
| 5 | 8 |
| 6 | 16 |
| 7 | 65 |
The structure of the compressed data is:
| Byte | Value |
|---|
| 1 .. 8 | Number of elements (64-bit little-endian number) |
| 9 .. 16 | Minumum element (currently unused) |
| 17 .. 24 | Maximum element (currently unused) |
| 25 .. 32 | Repeat length (used, starting with version 0.2) |
| 33 .. | Coded data |
Additional Compression Schemes
In addition, Andy Hammersley has proposed two types of lossless data compression algorithms
for CBF version 1.0. In later versions other types including lossy algorithms
may be added.
The first algorithm is referred to as byte_offsets and has been
chosen for the following characteristics: it is very simple,
may be easily implemented, and can easily lead to faster reading and
writing to hard disk as the arithmetic complication is very small.
This algorithm can never achieve better than a factor of two compression
relative to 16-bit raw data, but for most diffraction data the
compression will indeed be very close to a factor 2.
The second algorithm is referred to as predictor_huffman and has
been chosen as it can achieve close to optimum compression on typical
diffraction patterns, with a relatively fast algorithm, whilst avoiding
patent problems and licensing fees. This will typically provide a
compression ratio between 2.5 and 3 on well exposed diffraction images,
and will achieve greater ratios on more weakly exposed data e.g.
4 - 5 on "thin phi-slicing" images. Normally, this would be a two
pass algorithm; 1st pass to define symbol probabilities; second pass
to entropy encode the data symbols. However, the Huffman algorithm
makes it possible to use a fixed table of symbol codes, so faster single
pass compression may be implemented with a small loss in compression
ratio. With very fast cpus this approach may provide faster hard disk
reading and writing than the "byte_offsets" algorithm owing to the
smaller amounts of data to be stored.
There are practical disadvantages to data compression: the value of
a particular element cannot be obtained without calculating the values of
all previous elements, and there is no simple relationship between element
position and stored bytes. If generally the whole array is required this
disadvantage does not apply. These disadvantages can be reduced by
compressing separately different regions of the arrays, which is an
approach available in TIFF, but this adds to the complexity reading and
writing images.
For simple predictor algorithms such as the byte_offsets
algorithm a simple alternative is an optional data item, which defines a
look-up table of element addresses, values, and byte positions within
the compressed data, and it is suggested that this approach is followed.
THE "BYTE_OFFSETS" ALGORITHM
The byte_offsets algorithm will typically
result in close to a factor of two reduction in data storage size
relative to typical 2-byte diffraction images. It should give similar
gains in disk I/O and network transfer. It also has the advantage that
integer values up to 32 bits (31 bits unsigned) may be stored efficiently
without the need for special over-load tables. It is a fixed algorithm
which does not need to calculate any image statistics, so is fast.
The algorithm works because of the following property of almost all
diffraction data and much other image data: The value of one element
tends to be close to the value of the adjacent elements, and the vast
majority of the differences use little of the full dynamic range.
However, noise in experimental data means that run-length encoding is
not useful (unless the image is separated into different bit-planes). If
a variable length code is used to store the differences, with the number
of bits used being inversely proportional to the probability of
occurrence, then compression ratios of 2.5 to 3.0 may be achieved.
However, the optimum encoding becomes dependent of the exact properties
of the image, and in particular on the noise. Here a lower compression
ratio is achieved, but the resulting algorithm is much simpler and more
robust.
The byte_offsets algorithm is the following:
- The first element of the array is stored as a 4-byte signed
two's integer regardless of the raw array element type. The byte
order for this and all subsequent multi-byte integers is
little_endian regardless of the native computer architecture
i.e. the first byte is the least significant, and the last byte the
most. This value is the first reference value ("previous element") for
calculating pixel to pixel differences.
- For all elements, including the first element, the value of the
previous element is subtracted to produce the difference. For the first
element on a line the value to subtract is the value of the first element
of the previous line. For the first element of a subsequent image (or
plane) the value to subtract is the value of the first element of the
previous image (or plane).
- If the difference is less than +-127, then one byte is used to store
the difference as a signed two's complement integer, otherwise the byte
is set to -128 (80 in hex) and if the difference is less than
+-32767, then the next two bytes are used to store the difference as a
signed two byte two's complement integer, otherwise -32768 (8000 in hex,
which will be output as 00 80 in little-endian format) is written into
the two bytes and the following 4-bytes store the difference as a full
signed 32-bit two's complement integer.
- The array element order follows the normal ordering as defined by
the _array_structure_list entries index, precedence
and direction.
It may be noted that one element value may require up to 7 bytes for
storage, however for almost all 16-bit experimental data the vast
majority of element values will be within +-127 units of the previous
element and so only require 1 byte for storage and a compression factor of
close to 2 is achieved.
The PREDICTOR_HUFFMAN ALGORITHM
Section to be added.
OTHER SECTIONS
Other sections will be added.
9.0 REFERENCES
1. S R Hall, F H Allen, and I D Brown, "The Crystallographic Information
File (CIF): a New Standard Archive File for Crystallography",
Acta Cryst., A47, 655-685 (1991)
10.0 NOTES
(1) A pure ASCII CIF based format has been considered inappropriate given the
enormous size of many raw experimental data-sets and the desire for
efficient storage, and reading and writing.
However, an ASCII format is helpful for debugging software and
in understanding what has been written in a CBF when problems
arise, and there are other CIF application for which a convenience
binary format should be useful (e.g. illustrations in
a manuscript).
(2) Some simple method of checking whether the file is a CBF or not is
needed. Ideally this would be right at the start of the file. Thus, a
program only needs to read in n bytes and should then know immediately
if the file is of the right type or not. Andy though this identifier should
be some straightforward and clear ASCII string.
With the use of binary strings and MIME conventions identification of
a CBF versus a CIF is less critical than it was before, but the distinct
header as a simple ASCII string is still a good idea for the sake of the most efficient processing
of large files.
The underscore character has been used to avoid any ambiguity in the
spaces.
(Such an identifier should be long enough that it is highly unlikely to
occur randomly, and if it is ASCII text, should be very slightly
obscure, again to reduce the chances that it is found accidently. Hence
I added the three hashes, but some other form may be equally valid.)
(3) The format should maintain backward compatibility e.g. a version 1.0
file can be read in by a version 1.1, 3.0, etc. program, but to allow
future extensions the reverse cannot be guaranteed to be true.
However, prior to actual adoption of version 1.0, we are not
yet trying to ensure full upwards compatibility, just that the effort to
convert won't be unreasonable.
This page was produced on 23 April 2001
by Herbert J. Bernstein (email:
[email protected]),
based on the 14 November 1998 and 8 July 1998 versions and the
page produced by Andy Hammersley (E-mail: [email protected]).
